Product Infomation

Generic
 2 SIP Lines  HD Voice  PoE Enabled (only X301P)
 Dot-matrix display screen  Handset / Hands-free / Headset mode  Desktop Stand / Wall mountable
(optional)
 Optional External Power Supply
Phone Functions
 Local Phonebook (1000 entries)
 Remote Phonebook (XML/LDAP, 1000
entries)
 Call logs (In/Out/Missed, 600 entries)
 Blocked List/Allowed List
 Screen saver  Voice Message Waiting Indication
(VMWI)
 Programmable Softkeys  Network Time Synchronization  Support Poly wireless headset (Through
Poly APD-80 EHS Cable)
 Support Jabra wireless headset
(Through Fanvil EHS20 EHS Cable)
 Support Recording (Through Server)
 Action URL / Active URI
 XML Browser  Customize Boot Logo  uaCSTA
 Customize Incoming Call Ringtone  time Plan (timed reboot/timed
forward/timed upgrade/timed config)
 Hidden DTMF
 Ring From Headset
Call Functions
 Call out / Answer / Reject
 Mute / Unmute (Microphone)
 Call Hold / Resume  Call Waiting
 Intercom
 Caller ID Display
 Speed Dial
 Anonymous Call (Hide Caller ID)/Ban Anonymous call
 Call Forward (Always/Busy/No Answer)
 Call Transfer (Attended/Unattended)
 Call Parking/Pick-up (Depending on
server)
 Redial
 Predial
 Call Back
 Do-Not-Disturb(DND)/Timed DND
 Auto-Answering
 SIP SMS
 Voice Message (On server)
 6-way Audio Conference  Hot Line  Hot Desking
 Direct IP call without SIP proxy
 Action Plan  Dial Plan  Call Completion/Auto Redial
 Primary and Backup SIP Servers  Default Ext Line  Multicast
 Fuzzy Search Call
Audio
 HD Voice: HD handset, HD speaker  Wideband ADC/DAC 16KHz Sampling
 Narrowband Codec: G.711a/u, G.723.1,G.726,G.729,G.729A,G.729B,G.729
AB, iLBC
 Wideband Codec: G.722, Opus  Full-duplex Acoustic Echo Canceller (AEC)
 Voice Activity Detection (VAD) / Comfort
Noise Generation (CNG) / Background
Noise Estimation (BNE) / Noise Reduction
(NR) / Automatic Gain Control (AGC)
 Packet Loss Concealment (PLC)
 Dynamic Adaptive Jitter Buffer  DTMF: In-band, Out-of-Band (RFC2833/ SIP
INFO)
 VQM voice quality monitoring
Network
 Physical: 10/100 Mbps Ethernet, dual
bridged port for PC bypass  IP Mode: IPv4/IPv6/IPv4&IPv6
 IP Configuration: Static IP / DHCP / PPPoE
 Network Access Control: 802.1x  VPN: L2TP / OpenVPN
 VLAN
 LLDP
 QoS
 RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
 DNS-SRV (RFC 3263)
 Support Redundant Servers  Agent
 Https Mutual Authentication Protocols
 SIP v1 (RFC2543) v2(RFC3261)
 UDP/TCP/TLS
 RTP/RTCP/SRTP（Optional/Compulsory）
 STUN
 DHCP
 IPv6
 LLDP
 PPPoE
 802.1x  802.1p/Q
 L2TP
 OpenVPN
 SNTP
 FTP/TFTP
 HTTP/HTTPS
 TR-069
 AES128 & AES256
Deployment & Management
 Auto-Provisioning via
FTP/TFTP/HTTP/HTTPS/DHCPOPT66/SIPPNP/TR-069
 Screenshot
 Web Management Portal
 Web-based Packet Dump
 Configuration Export / Import
 Phonebook Import/Export
 Firmware Upgrade  Syslog
 Network Firewall
 Online Upgrade Physical Specifications
 LCD: 132x64 pixel graphical LCDwithbacklight
 Keypad: 33 keys, including
 4 Soft-keys  9 Function keys (Hold/Transfer/Voicemessage/Conference/Phonebook/MWI/Headset/Redial/Hands-free)
 4 Navigation keys  1 OK key
 12 Standard Phone Digits keys  3 Volume Control keys (Up/Down/Mute(Microphone/Red LEDindicator light)) Handset (RJ9) x1
 Standard RJ9 Handset Wire x1 1.5M CAT.5E Ethernet Cable x1 Desktop Stand x1
 Status Indicator Light x1 (Red)
 RJ9 Port x2: Handset x1, Headset x1 RJ45 Port x2: Network x1, PCx1(BridgedtoNetwork)
 Security Slot x1
 Power: DC5V / 0.6A or PoE
 POE complies with the IEEE802.3afstandard
 Power adapter:
Input:100-240VAC~50/60Hz Output:5V/0.6A
 Power Consumption(Adapter): 0.8~1.29W Power Consumption(PoE): 1.25~1.86W Working Temperature: 0~45℃ Working Humidity: 10~95% Installation:  Desktop Stand
 Wall mountable (optional )
 Color: Black
 N.W/CTN: 8.88kg(X301), 8.83kg(X301P) G.W/CTN: 9.68kg(X301), 9.63kg(X301P) Device Dimensions:  Desktop Stand (45°): 169x201.1x177.4mm
 Desktop Stand (50°): 169x191.9x185.8mm
 Wall mountable: 169x120.1x213.7mm Gift Box Dimensions: 250x220x55mm Outer CTN Dimensions: 460x300x270mm(10 PCS)
