Ubiquiti UniFi WiFi 7 Access Point PRO (U7-PRO) Ceiling-mounted WiFi 7 AP

(18 reviews)

KES 33,840

~~KES 36,000~~

Available

Shop top-quality laptops, desktops, monitors, networking devices, and accessories at Century Systems. Affordable prices, fast delivery, and expert support.

ADD TO CART

Share on

Description

Product Infomation

Overview

Dimensions

Ø206 x 46 mm (Ø8.1 x 1.8")

WiFi Standard

WiFi 7

Spatial Streams

Coverage Area

140 m² (1,500 ft²)

Max. Client Count

300+

Uplink

2.5 GbE

Mounting

Ceiling, Wall (Pro Mount Included)

Power Method

PoE+

Performance

MIMO

6 GHz

2 x 2 (DL/UL MU-MIMO)

5 GHz

2 x 2 (DL/UL MU-MIMO)

2.4 GHz

2 x 2 (DL/UL MU-MIMO)

Max. Data Rate

6 GHz

5.7 Gbps (BW320)

5 GHz

4.3 Gbps (BW240)

2.4 GHz

688 Mbps (BW40)

Antenna Gain

6 GHz

5.8 dBi

5 GHz

6 dBi

2.4 GHz

4 dBi

Max. TX Power

6 GHz

23 dBm

5 GHz

26 dBm

2.4 GHz

22 dBm

Max. BSSIDs

8 per Radio

Supported Data Rates

802.11be (WiFi 7)

7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)

802.11ax (WiFi 6/6E)

7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)

802.11ac (WiFi 5)

6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)

802.11n

6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Features

Wireless Meshing

Yes

Band Steering

Yes

802.11v BSS Transition Management

Yes

802.11r Fast Roaming

Yes

802.11k Radio Resource Management (RRM)

Yes

Advanced Radio Management

Yes

Passpoint (Hotspot 2.0)

Yes

Captive Hotspot Portal

Custom Branding Landing Page

Yes

Voucher Authentication

Yes

Payment-Based Authentication

Yes

External Portal Server Support

Yes

Password Authentication

Yes

Guest Network Isolation

Yes

Private Pre-Shared Key (PPSK)

Yes

WiFi Speed Limiting

Yes

Client Device Isolation

Yes

WiFi Schedules

Yes

RADIUS over TLS (RadSec)

Yes

Dynamic RADIUS-assigned VLAN

Yes

Hardware

Max. Power Consumption

21W

Supported Voltage Range

44—57V DC

Networking Interface

(1) 1/2.5 GbE RJ45 port

Weight

680 g (1.5 lb)

Management

Ethernet

Enclosure Material

Polycarbonate, metal

Mount Material

Stainless steel (SUS304), galvanized steel (SGCC)

LEDs

System

White/Blue

Channel Bandwidth

HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)

Certifications

CE, FCC, IC

Operating Frequency

US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz U-NII-5 to U-NII-8 : 5925 - 7125 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5725 MHz 5925 - 7125 MHz

Ambient Operating Temperature

-30 to 40° C (-22 to 104° F)

Ambient Operating Humidity

5 to 95% noncondensing
